Catheter Bonding Machine Equipment Line

Our catheter bonding technology allows your operators and technicians to perform various tube-to-tube and balloon-to-tube bonds/welds with increased speed and accuracy.

Quantum Tipping Machine

The Quantum is a tabletop tipping machine designed to produce superior outputs expected of the CATHTIP standard.

Magnum Tipping Machine

The Magnum provides the most flexible RF architecture on the market, capable of tip forming, flaring and bonding in production or Interface settings. Our state-of-the-art precision catheter forming systems produce the highest quality parts with speed and consistency. The Magnum can achieve flashless tips, smooth bonds, and exacting geometry with virtually all thermo-plastic materials.

Split Die Bonder

CT Split Die Bonder enables for two catheter ends (made with similar materials) to be sealed together and encased in heat shrink, helping to provide consistency to the seal.


The CT HOTBOX configures with other CATH-TECH equipment products. The CT HOTBOX offers improved yields consistent with normal standards. It provides ideal product positioning of the thermal nozzle to give operators the capability to achieve highly precise tube and shaft bonds with increased reliability. It is useful in operating under strict process controls. Our Hotbox comes with compatible guide inserts, and modifications can be made on the Y and Z axis to refine accuracy and accommodate a wide variety of product configurations.

Thermal Bonding

Robust and stable thermal bonding machine designed to provide the user with an effective and reliable production machine for bonding all sorts of balloon and catheter components with minimal cost of ownership. The BT-NG machine is a thermal bonding machine based on the hot-jaw principle. It incorporates 25 years of experience with the thermal bonding process. The small stainless steel dies used in the machines have accurate temperature control and heat up very fast.
